| CPU | D525 dual core 1.8G |
| Memory | DDRIII 1066/1333*1 2GB(up to 4GB) |
| Storage | 32GB SSD / Optional 64GB / 128GB SSD |
| LAN | 10/100/1000 Mbps gigabit Ethernet |
| Operation System | Windows 7, Windows XP, XPe, Linux (Ubuntu, Fedora), WEPOS, POS eady |
| Optional Peripherals | 3 tracks magnetic reader
Customer display module (2*20 VFD)
10.4" LCD 2nd display module |
| I/O Interface | 5* COM ports;
1*DB-VGA(15Pin D-sub);
1*DB25 Parallel port;
1* RJ-45 LAN port (1*Line-out, 1' MIC-in);
4* USB 2.0;
1* Audio out;
2*Internal Speaker(option);
1* PS2 mouse ;
1* PS2 key board. |
| Panel : | |
| Viewing Area | 15inches |
| Resolution | 800 x 600 or 1024 x 768 (max) |
| Active Display Area (mm) | 304.128 (W) x 228.96 (H)) |
| Display Color | 16,777,216 colors |
| Response Time | 8 MS |
| Contrast Ratio | 600 : 1 |
| Viewing Angle (Up/ Down/ Left/ R | 70°/ 60°/ 75°/ 75° |
| Touch Panel | 5-wire resistive |
| Luminance | 250 cd/m |
| Video Input (VGA Signal) | LVDS |
| Power Adaptor : | |
| Input | 110-240V/ AC 50-60HZ |
| Output | DC 12V/5A |
| Power Environment : | |
| Management | VESA DPMS |
| Consumption | 35W(max) |
| Storage Temperature | -20°C -- 60°C |
| Operating Temperature | 0°C -- 40°C |
| Operating Humidity | 10 % -- 85 % |
| Rotation | 130°(Vertical); 140°(Horizon) |
| Mounting (Standard) | VESA Compliant (100 mm x 100 mm) |
| Optional (Glass) | Strengthen Glass (for none-touch version) |
