| Body weight | Approx. IG-2D 166g, IG-2D BT 228g (incl. Battery) |
| Cradle weight | Approx. 147.4g/ 5.2oz |
| Dimension | Scanner : 75.00mm (W) x 171.31mm (H) x 82.85mm (L)
Cradle : 112.18mm (W) x 84.64mm (H) x 130.60mm (L) |
| Cable Length | 5ft (150cm) |
| Material | ABS Plastic and Rubber |
| Connector | RJ48 |
| Interface | RS-232, USB (HID KBW or Virtual comport) |
| Light Source | Visible red light 625nm LED |
| Scan Speed | 120 scans per second in 1D mode
60 images per second in 2D mode |
| Resolution | 752 (H) x 480 (V) pixels |
| Forward & Backward (Pitch) | ±60° (from front to back) |
| Left & Right (Skew) | ±60° (from plane parallel to symbol(side- to-side) ) |
| Rotational Tolerance | ±180° |
| Indicators | Green = good read |
| Operating Temp. | 0°C to 50°C (32°F to 122°F) |
| Storage Temp. | -20°C to 70°C (-4°F to 158°F) |
| Relative Humidity | 20% to 95% (Non-condensing) |
| Ambient light | 100,000 Lux Max. (Sunlight) |
| Sealing | Designed to IP54 water and dust protection |
| Bluetooth Module | Bluetooth V2.1 EDR |
| Frequency Band | 2.402GHz ~ 2.480GHz |
| Transmission Range | Up to 100M(328.08FT.) line of sight |
| RF Output Power | Class 1 (under 20dBm) |
| Cable Bending Test | 25,000 times minimum
(30 times/min @ 500g/90°) |
| Drop | 70.86 inches(180cm) drop on concrete surface |
